20 Amp Decora Plus Single Receptacle/Outlet, Commercial Grade, Self-Grounding

Environmental Specifications

Flammability : Rated V-2 per UL 94

Operating Temperature : -40°C to 60°C

Mechanical Specifications

Product ID : Ratings are permanently marked on device

Terminal Accom. : 14-10 AWG

Terminal ID : Brass-Hot, Green-Ground, White-Neutral

Termination : Back or Side Wire

Electrical Specifications

Amperage : 20 A

Current Limiting : Full Rated Current

Dielectric Voltage : Withstands 2000V per UL498

Grounding : Self-Grounding

Pole : 2

Temperature Rise : Max 30C after 250 cycles OL at 200 percent rated current

Voltage : 250 VAC

Wire : 3

Product Features

Amperage : 20 A

Body Material : Thermoplastic Nylon

Brand : Decora Plus

Color : Ivory

Device Type : Single Receptacle Outlet

Face Material : Thermoplastic Nylon

Feature 4 : Smooth Face

Grade : Commercial Specification Grade

Grounding : Self-Grounding

NEMA : 6-20R

Pole : 2

Standards and Certifications : UL

Strap Material : Steel

Termination : Back or Side Wire

Voltage : 250 VAC

Warranty : 10-Year Limited

Wire : 3

Material Specifications

Body Material : Thermoplastic Nylon

Clamp Nuts : Zinc-Plated Steel

Face Material : Thermoplastic Nylon

Ground Clips : Brass-Plated

Grounding Screw : Brass 8-32

Line Contacts : Brass Triple-Wipe .031 Thick

Terminal Screws : Brass 10-32

Yoke : Zinc-Plated Steel

AC Horsepower Ratings

At Rated Voltage : 2 HP

Standards and Certifications

ANSI : C-73

NEMA : WD-6

NOM : 057

UL498 : File E13399
