15 Amp Isolated Ground Duplex Receptacle/Outlet, Industrial Grade, Self-Grounding

Environmental Specifications

Flammability : Rated V-2 per UL 94

Operating Temperature : -40°C to 60°C

Electrical Specifications

Amperage : 15 A

Current Limiting : Full Rated Current

Dielectric Voltage : Withstands 2000V per UL498

Grounding : Self-Grounding

Pole : 2

Temperature Rise : Max 30C after 250 cycles OL at 200 percent rated current

Voltage : 250 VAC

Wire : 3

AC Horsepower Ratings

At Rated Voltage : 1-1/2 HP

Material Specifications

Body Material : Thermoplastic Nylon

Clamp Nuts : Galvanized Steel

Color : Orange

Face Material : Thermoplastic Nylon

Grounding Screw : Brass 8-32

Isolated Ground System : Brass

Line Contacts : Phosphor Bronze

Strap Material : Galvanized Steel

Terminal Screws : Plated Brass

Product Features

Body Material : Thermoplastic Nylon

Color : Orange

Device Type : Duplex Receptacle Outlet

Face Material : Thermoplastic Nylon

Feature 4 : Smooth Face

Function : Isolated Ground

Grade : Heavy-Duty Industrial Specification Grade

NEMA : 6-15R

Termination : Back or Side Wire

Mechanical Specifications

Product ID : Ratings are permanently marked on device

Screw Terminal Torque : 14-18 in-lbs

Terminal Accom. : 14-10 AWG

Terminal ID : Brass-Hot, Green-Ground, Silver-Neutral

Termination : Back or Side Wire

Torque Range : 14-16 inch pounds

Standards and Certifications

ANSI : C-73

CSA C22.2 No. 42 : File 152105

NEMA : WD-6

NOM : 057

UL Fed Spec WC-596 : File E13399

UL498 : File E13399

Warranty : 10-Year Limited
