Occupancy Sensor, Microwave, Surface Mount, 120-277V, 1664SF, White

Warranty

Warranty : 5-Year Limited

Type

Product Type : Occupancy Sensor

Mechanical Specifications

IP Rating : IP20

Mounting Type : Surface Mount or Base Mount

Size : Height 3.2" (82mm), Width 1.73" (44mm), Depth 1.05" (26.84mm)

Product Features

Application : Garages, Warehouses, Metal Walls or Fixtures Including Wall Sconces and Wall Packs

Color : White

Grade : Commercial

Mounting : Surface Mount or Base Mount

Mounting Height (Ft.) : Up to 32 FT

Product Line : OSM3D

Sensor Technology : Microwave

Sensor Type : Occupancy

Switch Type : Single-Pole

Time Delay : 10s-30m

Performance Specifications

Coverage (Sq.Ft.) : 1664.0

Foot Candle Level : 0.46FC (5lux)/1.39FC (15lux)/2.78FC (30lux)/4.64FC(50lux)/disable

Pattern : Wall: 150° Ceiling: 360°

Electrical Specifications

Frequency : 50/60Hz

Load Rating : Tungsten: 800 W @ 120VAC, Electronic Driver/Ballast: 1000VA @ 120VAC, Driver: 1200VA @ 277VAC

Neutral Wire Connection : Required

Power Consumption : ≤0.5W (standby) - <1W (operation)

Voltage : 120-277 VAC

Environmental Specifications

Relative Humidity : 20% to 90% non-condensing
